- Vibration device is added to the cross wire feeding system to prevent wire winding.
- The line wire and the cross wire are precise positioning, mesh panel is flat, mesh hole is standard.
- Cross wire spacing adjusted through the HMI, different mesh sizes can set in the same mesh.
- The upper and lower dies of the bending machine move at the same time to save time.
- We can easily adjust the welding current when we need to weld different wire diameters.
- We can set the output and stop the machine automatically after the mesh production finished.
- Wire feeding, mesh welding, mesh bending, mesh stacking running together, High production efficiency.
- Robot mesh stacking system can accurately and quickly place the mesh, saving labour cost. ( opt. attachment )
3D Panel Weld Mesh Machine
Overview
Our advanced machinery is specifically designed to optimize the welding process, delivering high precision and consistency across all panels produced. Capable of creating custom designs and dimensions, our machines serve a diverse array of applications, including construction, fencing, and industrial uses by integrating cutting-edge technology with efficient production methods.
Specification
Technical Specifications
| 3D FENCE PANEL WELDING MACHINE | MECHANICAL TYPE | AUTOMATIC BENDING | ||||||||||
| MODEL | AWM – 3D/25 | AWM – 3D/30 | AWM – 3D/25A | AWM – 3D/30A | ||||||||
| Line Wire Dia (Pre-cut) | 3-6mm | 3-6mm | 3-6mm | 3-6mm | ||||||||
| Cross Wire Dia (Pre-cut) | 3-6mm | 3-6mm | 3-6mm | 3-6mm | ||||||||
| Line Wire Space | 3-5mm, 50-300mm, 5-6mm, 100-300mm | 3-5mm, 50-300mm, 5-6mm, 100-300mm | 3-5mm, 50-300mm, 5-6mm, 100-300mm | 3-5mm, 50-300mm, 5-6mm, 100-300mm | ||||||||
| Cross Wire Space | 12.5-300mm | 12.5-300mm | 12.5-300mm | 12.5-300mm | ||||||||
| Max. mesh width (Fence width) | 2500mm | 3000mm | 2500mm | 3000mm | ||||||||
| Max. mesh length (Fence height) | 3000mm | 3000mm | 3000mm | 3000mm | ||||||||
| Max. welding speed | 50-75 times/min | 50-75 times/min | 50-75 times/min | 50-75 times/min | ||||||||
